HSB spiral

Description

I asked Chatgpt to put all rgb colors in an hsb spiral.


import numpy as np
from PIL import Image
import colorsys
import itertools

# --- CONFIG ---
IMAGE_SIZE = 4096
TOTAL_COLORS = IMAGE_SIZE * IMAGE_SIZE

# --- STEP 1: Generate All RGB Colors and Sort by HSB ---
print("Generating and sorting colors...")

def rgb_to_hsb(rgb):
    r, g, b = [x / 255.0 for x in rgb]
    h, s, v = colorsys.rgb_to_hsv(r, g, b)
    return (h, s, v)

# Generate all RGB colors
all_colors = np.array(list(itertools.product(range(256), repeat=3)), dtype=np.uint8)
sorted_colors = sorted(all_colors, key=rgb_to_hsb)

# --- STEP 2: Generate Spiral Coordinates (Corrected Version) ---
print("Generating correct spiral coordinates...")

def generate_spiral_coords(size):
    coords = np.zeros((size * size, 2), dtype=np.int32)
    x, y = size // 2, size // 2
    dx, dy = 1, 0  # Start by moving right
    steps = 1      # Number of steps in current leg
    idx = 0

    while idx < size * size:
        for _ in range(2):  # Each step count is repeated twice (x and y direction)
            for _ in range(steps):
                if 0 <= x < size and 0 <= y < size:
                    coords[idx] = (x, y)
                    idx += 1
                    if idx >= size * size:
                        return coords
                x += dx
                y += dy
            # Rotate direction: right → down → left → up
            dx, dy = -dy, dx
        steps += 1

    return coords

spiral_coords = generate_spiral_coords(IMAGE_SIZE)

# --- STEP 3: Paint the Image ---
print("Painting the image...")
image_array = np.zeros((IMAGE_SIZE, IMAGE_SIZE, 3), dtype=np.uint8)

for idx, (x, y) in enumerate(spiral_coords):
    image_array[y, x] = sorted_colors[idx]

# --- STEP 4: Save the Image ---
print("Saving image...")
image = Image.fromarray(image_array, 'RGB')
image.save("spiral_hsb_rgb_universe_fixed.png", "PNG")

print("Done! Image saved as 'spiral_hsb_rgb_universe_fixed.png'")

Author

ACJ
53 entries

Stats

Date
Colors16,777,216
Pixels16,777,216
Dimensions4,096 × 4,096
Bytes30,563,133
